1 Magneto-infrared system

The system is the result of long-term in-house development and prototyping. It currently achieves simultaneous operation at magnetic fields of 0-12 T (with compatibility for higher-field magnets), temperatures of 2-300 K, and a wavelength range of 1-200 μm (50-10,000 cm^-1), with a signal-to-noise ratio of 2×10⁴ (0.005% noise) and a spectral resolution of 0.02 meV. It further supports in-situ linear and circular polarization resolution, and has been providing long-term open access to users across disciplines worldwide. The current beam spot size is ~1 mm, suitable for samples larger than 0.1 mm. A microscopy-based version of the magneto-infrared spectroscopy system is under development and is expected to be available by 2028.

2 Spectrum

Nano-spectroscopy: supports fluorescence, Raman, transmission/reflection, and photocurrent measurements; operating temperature range 4-500 K; spectral range 300-1100 nm.

Infrared microscope: supports transmission/reflection and photocurrent spectroscopy; operating temperature range 77-500 K; spectral range 400-20,000 cm^-1.

3 Magnet

TeslatronPT Magnet (12 T)

SpectromagPT Magnet (7 T)

Room-Temperature Bore Magnet (12 T)

Transport Measurement System Compatible with the Above Magnets: operating temperature range 2–300 K; supports DC/AC measurements and angle-dependent studies.

4 Micro-nano Processing System

Projection lithography (home-built): Resolution 1 μm

Transfer & stacking platform (home-built)

Probe Station (home-built)

Magnetron sputtering

Glove-box

5 Crystal Growth

Several Tube furnace and Muffle furnace for crystal growth/chemical vapor transport.
